PLACA DE RED GIGA PCIE TP LINK TG 3468

CARACTERÍSTICAS DE HARDWARE

Estándares y Protocolos: IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1q, 802.1p, CSMA/CD, TCP/IP

Interface: 32-bit PCI Express

   1 10/100/1000Mbps RJ45 port

Medios de Red 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100BASE-TX: UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

1000Base-T: UTP category 5, 5e cable (maximum 100m)

Velocidad de Datos: 10/100/1000Mbps for Half-Duplex mode

    20/200/2000Mbps for Full-Duplex mode

Indicador LED: 1000Mbps Link/Act, 100Mbps Link/Act, 10Mbps Link/Act

Control de Flujo: IEEE 802.3x Flow Control (Full-Duplex)

Contenidos del Paquete: Gigabit PCI Express Network Adapter TG-3468

Resource CD

Quick Installation Guide

Requisitos del Sistema: Windows 7(32/64bits),Windows Vista(32/64 bits),Window XP(32/64bits)

Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
